ฟังก์ชั่น
- ตั้งค่าล่วงหน้า
- Zero/ABS
- power On/Off Data hold (คงค่าข้อมูล)
- Data out put (ส่งออกข้อมูล)
- Error alarm (แจ้งเตือนความผิดพลาด).
- แจ้งเตือนให้เปลี่ยนแบตเตอรี่
ฟังก์ชั่น
Technical Data
Accuracy: Refer to the list of specifications.
Resolution: 0.001mm or .00005″/0.001mm (over 5″ models: .0001″/0.001mm)
Contact point:TiN-coating
Measuring method: Three-point method
Display: LCD
Battery: SR44 (2 pcs.), 938882
Battery life: Approx. 8 months under normal use
Function
Zero-setting, Data hold, Data output, Preset, inch/mm conversion (inch/mm models)
Alarm: Low voltage, Counting value composition error
Optional Accessories
05CZA662: SPC cable (1m / 40”)
05CZA663: SPC cable (2m / 80”)
04AZB157: Mounting plate for stand
156-101: Stand
952322: Extension rod 100mm / 3.94” For range 6-12mm / .275 – .5” models
952621: Extension rod 150mm / 5.9” For range 12-20mm / .5″ – .8” models
952622: Extension rod 150mm / 5.9” For range 20-50mm / .8″ – 2” models
952623: Extension rod 150mm / 5.9” For range 50-300mm / 2″ – 12” models
Order No | Model | Range | Head Assy Order No. | Accuracy | Remarks |
468-161 | HTD-8R | 6-8mm | 04AZB136 | 2µm | – |
468-162 | HTD-10R | 8-10mm | 04AZB137 | 2µm | – |
468-163 | HTD-12R | 10-12mm | 04AZB138 | 2µm | – |
468-164 | HTD-16R | 12-16mm | 04AZA719 | 2µm | with TiN-coated contact points |
468-165 | HTD-20R | 16-20mm | 04AZA720 | 2µm | with TiN-coated contact points |
468-166 | HTD-25R | 20-25mm | 04AZA728 | 2µm | with TiN-coated contact points |
468-167 | HTD-30R | 25-30mm | 04AZA729 | 2µm | with TiN-coated contact points |
468-168 | HTD-40R | 30-40mm | 04AZA737 | 2µm | with TiN-coated contact points |
468-169 | HTD-50R | 40-50mm | 04AZA738 | 2µm | with TiN-coated contact points |
468-170 | HTD-63R | 50-63mm | 04AZA750 | 2µm | with TiN-coated contact points |
468-171 | HTD-75R | 62-75mm | 04AZA751 | 2µm | with TiN-coated contact points |
468-172 | HTD-88R | 75-88mm | 04AZA752 | 2µm | with TiN-coated contact points |
468-173 | HTD-100R | 87-100mm | 04AZA753 | 2µm | with TiN-coated contact points |
468-174 | HTD-125R | 100-125mm | 04AZA775 | 2µm | with TiN-coated contact points |
468-175 | HTD-150R | 125-150mm | 04AZA776 | 2µm | with TiN-coated contact points |
468-176 | HTD-175R | 150-175mm | 04AZA777 | 2µm | with TiN-coated contact points |
468-177 | HTD-200R | 175-200mm | 04AZA778 | 2µm | with TiN-coated contact points |
468-178 | HTD-225R | 200-225mm | 04AZA779 | 2µm | with TiN-coated contact points |
468-179 | HTD-250R | 225-250mm | 04AZA780 | 2µm | with TiN-coated contact points |
468-180 | HTD-275R | 250-275mm | 04AZA781 | 2µm | with TiN-coated contact points |
468-181 | HTD-300R | 275-300mm | 04AZA782 | 2µm | with TiN-coated contact points |
