Sumitomo

WFX MILLING CUTTERS

SKU: WFX series Categories: ,



HIGH PRECISION SHOULDER MILLING CUTTERS

Wave Mill WFX type for shoulder milling is a screw-locking type cutter capable of using four corners. Ideal cutting edge design delivers good squareness.

  • Stable machining due to sharp cutting edge
  • Shank type / Shell Type / Modular Type
  • Standard / Fine pitch / Extra-fine pitch
  • Wide milling cutter range with diameter from Ø 20mm to 100mm



OPTIMIZED EDGE SHAPE

The insert shape, optimized for shoulder milling and combined with a high-precision body, leaves a superior machined surface finish.

  • Convex shape ensures the cutting edge strength
  • Flat shape minimises differences in step levels
  • Wiper edge function improves the surface roughness



EXPANSION FOR HIGH FEED AND CHAMFER MILLING

WFXH TYPE
Wave Mill WFXH type is a high efficiency multi-purpose cutter, that uses the WFX series inserts for high feed roughing and a variety of processes.
  • Modular Type available
  • Ramping and helical milling
  • Milling cutter range from Ø 25mm to 40mm

WFXC TYPE
The WaveMill WFXC type enables chamfer milling with the same inserts of WFX series. This allows the WFXC chamfering tool to support many types of work materials using a variety of grades.
  • Modular Type available
  • Milling cutter range from Ø 8mm to 32mm
