BACK-JAW CENTERLINE CALIPER

  • Allows quick measurement of a distance between hole centers
  • This back jaw type enables measurement of a hole while viewing it from the front
  • Specially designed to measure hole Centerto-Center and Edge-to-Center distances. Provided with jaws on the back of the slider, measurements can be read easily from above.
  • Direct reading of pitch measurements is available due to the offset value setting function.
  • Allows integration into statistical process control and measurement systems for models with measurement data output connector.
  • Dedicated calibration inspection tools are available

Metric Edge-to-center distance type

Order No.Range (mm)Accuracy (mm)
573-718-20 *110.1 – 200±0.10
573-719-20 *110.1 – 300±0.15

*1 Applicable hole diameter: ø1.5 – ø19.5 mm



Metric Center-to-center distance type

Order No.Range (mm)Accuracy (mm)
573-716-20 *210.1 – 200±0.10
573-717-20 *210.1 – 300±0.15

*2 Applicable hole diameter: ø1.5 – ø9.5 mm
