- Rotating Parabolic Reflector: For enhanced visibility from a distance.
- Flashing Cycle: 160 times/min.
- Built-in Alarm: Intermittent buzzer volume up to 85dB at 1m.
- Installation: Upright only.
- Main Body: Impact and heat resistant ABS resin.
- Lens: Superior weather resistant and light translucent AS resin.
- Spare Bulb: Included.
- Available Colors: Red, Amber, Green, Blue
PATLITE
KJSB 82mm Rotating
The KJSB series is a compact cube tower with a buzzer, featuring a design to be used for applications with small equipment.
| DIMENSIONS | – 82mm square |
|---|---|
| RATED VOLTAGE | – 12V DC – 24V DC – 120V AC – 220V AC |
| FUNCTIONS | – Rotating with Alarm |
| MOUNTING | – Direct Mount – Indoors (Upright Only) |
| BODY STYLE | – Square Base, colored Lens – pre-assembled, pre-wired – Lens Colors interchangeable, not stackable after purcha |
| BODY COLOR | – Body: Beige |
| STACKABLE TIERS | – Fixed frame: 1, 2, 3 or 4-tier versions available |
| GLOBE COLOR | – Light Source: Bulb – Lens Colors: Red / Amber / Green / Blue |
| GLOBE MATERIAL | – Acrylic Resin |
| AUDIBLE STYLE | – An integral intermittent tone – Max. 85dB at 1 meter |
| PROTECTION RATING | – IP-23 |
| OPTIONS | – SZ-30L – SZ-30T – SZ-007 |
