PATLITE

KJSB 82mm Rotating

The KJSB series is a compact cube tower with a buzzer, featuring a design to be used for applications with small equipment.

  • Rotating Parabolic Reflector: For enhanced visibility from a distance.
  • Flashing Cycle: 160 times/min.
  • Built-in Alarm: Intermittent buzzer volume up to 85dB at 1m.
  • Installation: Upright only.
  • Main Body: Impact and heat resistant ABS resin.
  • Lens: Superior weather resistant and light translucent AS resin.
  • Spare Bulb: Included.
  • Available Colors: Red, Amber, Green, Blue
DIMENSIONS– 82mm square
RATED VOLTAGE– 12V DC
– 24V DC
– 120V AC
– 220V AC
FUNCTIONS– Rotating with Alarm
MOUNTING– Direct Mount
– Indoors (Upright Only)
BODY STYLE– Square Base, colored Lens
– pre-assembled, pre-wired
– Lens Colors interchangeable, not stackable after purcha
BODY COLOR– Body: Beige
STACKABLE TIERS– Fixed frame: 1, 2, 3 or 4-tier versions available
GLOBE COLOR– Light Source: Bulb
– Lens Colors: Red / Amber / Green / Blue
GLOBE MATERIAL– Acrylic Resin
AUDIBLE STYLE– An integral intermittent tone
– Max. 85dB at 1 meter
PROTECTION RATING– IP-23
OPTIONS– SZ-30L
– SZ-30T
– SZ-007
