PLA CLAMPING KITS

Material ENGINEERING PLASTIC (PBT RESIN)

Feature

  • World’s first engineering plastic (PBT resin) clamping set.
  • The material used offers excellent strength and rigidity, and has the highest level elasticity among engineering plastics.
  • Lightweight at 1/1 of steel. Easy to carry and able to reduce set-up time.
  • Does not rust, making it ideal for clamping in locations and for workpieces where rust is a problem, and allowing it to be used while constantly clean.
  • Capable of soft clamping without scratching the workpiece. Useful for clamping of soft materials and finished products.
  • Ideal for clamping the item to be measured such as with a coordinate measuring machine and will not damage tables or workpieces or cause injuries if dropped.
  • Can also be used as a clamp for electrical discharge machines. Can be used with both synthetic and mineral machining liquids.
  • Can also be used as a clamp for light work such as engraving.
  • Employs aluminum (A556) stud bolts for increased strength and rigidity. Rust resistant with alumite treatment.
  • Innovative design that gives full consideration to functionality.



Content of Set




Characteristics of Plastic Used


PropertySpecific

Gravity

Water

Absorption

Ratio

Heat

Distortion

Temperature

Thermal

Conductivity

Linear

Expansion

Coefficient

Fire

Resistance

Units%cal/(cm・s・℃)1℃UL 94 standard
Conditions23℃20°C for 30 days18.6kg/cm-30℃~+30℃1.6mmBar
Data1.410.352084.0×10-43~8×10-5HB



PropertyTensile

Strength

Yield

Point

Tensile

Rupture

Point

Bending

Strength

Bending

Elasticity

Izod

Impact

Strength

Insulation

Breakdown

Strength

Arc

Resistance

UnitsN/mm2%N/mm2N/mm2kJ/m2kv/msec
Conditions23℃23℃23℃23℃1/8″ × 1/2″ 23°C

bar with notch

D149D495
Data974~61705200650Short time method 20

Step method 15

125
No.Matching Screw Diameter (Coarse Thread)Weight(kg)
PCS0006M 6-M81.7
PCS0008M 8-M81.7
PCS0010M10-M81.7
PCS0012M12-M81.8
