Inch
| Range | Order No | Graduation | Accuracy | Force | Remark |
|---|---|---|---|---|---|
| 0-.5in | 7300S | .001in | .001in | less than 1.4N | Standard, ceramic spindle/anvil |
| 0-1in | 7304S | .001in | .002in | less than 2.0N | Standard, ceramic spindle/anvil |
| 0-1in | 7322S | .001in | .002in | less than 2.0N | Deep throat, ceramic spindle/anvil |
| 0-.05in | 7326S | .0001in | .0002in | less than 1.4N | Fine dial reading, ceramic spindle/anvi |
Metric
| Range | Order No | Graduation | Accuracy | Force | Remark |
|---|---|---|---|---|---|
| 0-10mm | 7301 | 0.01mm | 15µm | less than 1.4N | Standard, ceramic spindle/anvil |
| 0-20mm | 7305 | 0.01mm | 20µm | less than 2.0N | Standard, ceramic spindle/anvil |
| 0-10mm | 7321 | 0.01mm | 15µm | less than 1.4N | Deep throat, ceramic spindle/anvil |
| 0-20mm | 7323 | 0.01mm | 22µm | less than 2.0N | Deep throat,ceramic spindle/anvil |
