Inch
| Graduation | Range Range/Rev | Order No | Type | Dial Reading | Accuracy First 2.5 Rev/Overall | Force |
|---|---|---|---|---|---|---|
| .0001in | .25” / .01” | 2356S-10 | w/lug | 0-10 | .0001 / .0005 | 2.0N or less |
| .0001in | .25” / .01” | 2356SB-10 | Flat-back | 0-10 | .0001 / .0005 | 2.0N or less |
| .0001in | .5” / .01” | 2358S-10 | w/lug | 0-10 | .0001 / .0008 | 2.0N or less |
| .0001in | .5” / .01” | 2358SB-10 | Flat-back | 0-10 | .0001 / .0008 | 2.0N or less |
| .001in | .5” / .1” | 2414S | w/lug | 0-100 | .001 / .001 | 1.8N or less |
| .001in | .5” / .1” | 2414SB | Flat-back | 0-100 | .001 / .001 | 1.8N or less |
| .001in | .5” / .1” | 2415S | w/lug | 0-50-0 | .001 / .001 | 1.8N or less |
| .001in | .5” / .1” | 2415SB | Flat-back | 0-50-0 | .001 / .001 | 1.8N or less |
| .001in | 1″ / .1” | 2416S | w/lug | 0-100 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2416S-06* | w/lug | 0-100 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2416S-10 | w/lug | 0-100 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2416SB | Flat-back | 0-100 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2416SB-06* | Flat-back | 0-100 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2416SB-10 | Flat-back | 0-100 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2417S | w/lug | 0-50-0 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2417SB | Flat-back | 0-50-0 | .001 / .002 | 1.8N or less |
| .001in | 2″ / 1” | 2424S-19 | w/lug | 0-100 | .001 / .003 | 2.5N or less |
| .001in | 2″ / 1” | 2424SB-19 | Flat-back | 0-100 | .001 / .003 | 2.5N or less |
| .0005in | .125” / .05” | 2506S | w/lug | 0-50 | .0005 / .0005 | 1.8N or less |
| .0005in | .125” / .05” | 2506SB | Flat-back | 0-50 | .0005 / .0005 | 1.8N or less |
| .0005in | .125” / .05” | 2507S | w/lug | 0-25-0 | .0005 / .0005 | 1.8N or less |
| .0005in | .125” / .05” | 2507SB | Flat-back | 0-25-0 | .0005 / .0005 | 1.8N or less |
| .0005in | .5” / .05” | 2514S | w/lug | 0-50 | .0005 / .0015 | 1.8N or less |
| .0005in | .5” / .05” | 2514SB | Flat-back | 0-50 | .0005 / .0015 | 1.8N or less |
| .0005in | 1″ / .05” | 2776S | w/lug | 0-50 | .0005 / .002 | 2.5N or less |
| .0005in | 1″ / .05” | 2776SB | Flat-back | 0-50 | .0005 / .002 | 2.5N or less |
| .0001in | .025” / .01” | 2802S-10 | w/lug | 0-10 | .0001 / .0001 | 2.0N or less |
| .0001in | .025” / .01” | 2802SB-10 | Flat-back | 0-10 | .0001 / .0001 | 2.0N or less |
| .0001in | .025” / .01” | 2803S-10 | w/lug | 0-5-0 | .0001 / .0001 | 2.5N or less |
| .0001in | .025” / .01” | 2803SB-10 | Flat-back | 0-5-0 | .0001 / .0001 | 2.5N or less |
| .0001in | .05” / .01” | 2804S-10 | w/lug | 0-10 | .0001 / .0002 | 2.0N or less |
| .0001in | .05” / .01” | 2804SB-10 | Flat-back | 0-10 | .0001 / .0002 | 2.0N or less |
| .0001in | .05” / .01” | 2805S-10 | w/lug | 0-5-0 | .0001 / .0002 | 2.0N or less |
| .0001in | .05” / .01” | 2805SB-10 | Flat-back | 0-5-0 | .0001 / .0002 | 2.0N or less |
| .001in | 1″ / .1” | 2904S | w/lug | 100-0 | .001 / .002 | 1.8N or less |
| .001in | 1″ / .1” | 2904SB | Flat-back | 100-0 | .001 / .002 | 1.8N or less |
| .0001in | .05” / .01” | 2905S-10 | w/lug | 0-10 | .0001 / .0002 | 2.0N or less |
| .0001in | .05” / .01” | 2905SB-10 | Flat-back | 0-10 | .0001 / .0002 | 2.0N or less |
| .0005in | .125” / .05” | 2922S | w/lug | 0-25-0 | .0005 / .0005 | 1.8N or less |
| .0005in | .125” / .05” | 2922SB | Flat-back | 0-25-0 | .0005 / .0005 | 1.8N or less |
| .0001in | .05” / .01” | 2923S-10 | w/lug | 0-5-0 | .0001 / .0002 | 2.0N or less |
| .0001in | .05” / .01” | 2923SB-10 | Flat-back | 0-5-0 | .0001 / .0002 | 2.0N or less |
