RT-A1-02
Revolving Warning Light
PATLITE

RT-A/C/D/E 162mm Revolving Warning Light

The RT series is a large horn and rotating light combination for increased plant floor coverage.

Download Catalogue
Categories: ,
  • 32 sounds are pre-recorded in one unit.
  • For enhanced durability and safety in the work environment.
  • Built-in Alarm: Adjustable audible sound up to 105dB at 1m with volume control.
  • Installation: Indoors—upright, inverted, sideways; Outdoors—upright only. (Do not install the horn facing upward).

※PATLITE Corporation has not applied for permission to use certain copyrighted music or songs recorded in RT-A, C and D types outside of Japan. For additional information regarding this issue, please contact your local PATLITE sales representative.

DIMENSIONS – 162mm diameter
RATED VOLTAGE – 24V DC
– 100V AC
– 200V AC
AUDIBLE STYLE – RT-A/C/D/E: 32 pre-recorded alarm sounds
SOUND SELECTION – High-quality digital recording
VOLUME – Maximum 105dB at 1 meter with adjustable volume control
STACKABLE TIERS – Dry contact closure such as switches or relay contacts
– Open-collector transistor (NPN for DC24V and AC120V)
– Direct voltage control for DC24V, K and L-type Units only (see wiring diagrams)
GLOBE COLOR – Red
– Amber
– Green
– Blue
GLOBE MATERIAL -AS Resin
PROTECTION RATING – IP23 (IP65 by special order)
OPTIONS – SZ-008
